・Thin Design
Our thinnest to match the miniaturization of production line equipment, with a compact design having a depth of only 19.9mm. A maximum sound of 87 dB (at 1m) can be reached with such a thin shape. The volume adjustment is easily accessible from the front panel, and a low power of 3.5W (max.) takes an extra load off the power supply.
・Easy Installation
With only the need to access it from the front, the cover is easily removable for installation and volume adjustment, which can reduce labor time for maintenance, etc.
・Message Rewriteing
The SD card slot, as a standard accessory, allows the rewriting of MP3 data with an SD card. In addition to message rewriting with the exclusive application software, it is possible to change MP3 data file names or rewrite it without the application software
| 额定电压 | - DC12/24V |
|---|---|
| MOUNTING OPTIONS | - Panel mount in the Upright Position |
| 主体颜色 | - Dark Gray - Off White - Silver |
| 音量 | - Maximum 87dB at 1 meter (For Panel Mount) - Maximum 85dB at 1 meter (For Wall Mount) |
| 存储内容 | - Approximate Recording Time: 63 seconds (Bit rate=64k/s) |
| 输出频道 | - Bit Input: 5 (Sound Reduction Mode: 4) - Binary Input: 31 (Sound Reduction Mode: 7) |
| 认证 | - CE Marking - UL - RoHS |
| 防护等级 | - Panel Mount: IP54 (Upright Only) - Wall Mount: IP20 |
| 可选择的播放模式 | - Normal Playback - Hold Playback - Priority Input Playback - Memory Playback |
| CONTROL OPTIONS | - PNP Transistor - NPN Transistor |
| OPTIONAL HARDWARE | - Playlist Editor (Free Software Version) - SDV-128P: SD Card (for mp3 file transfer and storage)* *Other SD cards not guaranteed to work |
