BKV
系列可录制式报警器BKV
具备31个频道63秒报警播放，可嵌入面板，大音量，防护等级高
BKV系列采用音质清晰的MP3文件作为音源，可使用SD卡简单储存更换音频文件。
·嵌入式设计，实现与机械的一体化；根据机械外观有2种颜色可以选择。
·最大音量为95分贝（在1米处测试）可用于各种嘈杂的工厂环境或大设备的远距离警示。
·无需拆装主体也可更换音源的SD卡输入设计。
·录音总长达到63秒，可使用5个频道的接点式控制，也可使用31频道的二进制控制。
| 尺寸 | - 120mm x 120mm x 62.8mm |
|---|---|
| 额定电压 | - DC12/24V - AC100V* *Special Order Item |
| MOUNTING OPTIONS | - Panel Mount - Vertical mounting angle only - Indoor: Upright, upside-down, sideways - Outdoor: Upright only |
| 主体颜色 | - Dark Gray - Beige |
| 音量 | - Maximum 95dB at 1 meter - Adjustable volume control |
| 存储内容 | - Approximate Recording Time: 63 seconds (Bit rate=64k/s) |
| 输出频道 | - Bit Mode: Select from 1 to 5 channels available with a signal input - Binary Mode: Select from 1 to 31 channels available with a signal input |
| 认证 | - CE Marking - RoHS |
| 防护等级 | - IP-54 (Upright Only) |
| 可选择的播放模式 | - Momentay Input: Message plays once - Sustained Input: Message repeats until input is open |
| OPTION BRACKET | - Dry contact closure such as switches or relay contacts - Open-collector transistor (NPN only) |
| OPTIONAL HARDWARE | - Playlist Editor Program (for mp3 file arrangement)* - SDV-128P:SDCard (for mp3 file transfer and storage)** *Available from Patlite with purchase of BKV unit **Other SD cards not guaranteed to work |
