80mm 可录制式报警器
BDV

具备15个频道63秒报警播放,可嵌入面板,防护等级高

  • 输入输出控制
  • □80
  • 可录音报警器
  • 语音
  • 87dB
  • 室内
  • 室外
  • IP54
  • 80mm 可录制式报警器 BDV

BDV系列采用音质清晰的MP3文件作为音源,可使用SD卡简单存储更换音频文件,轻松嵌入机械面板。
嵌入式设计,实现与机械的一体化:根据机械外观有2种颜色可以选择。
最大音量为87分贝(在1米处测试),可用于电子加工,液晶面板加工等生产工序。
无需拆装主体也可替换音频文件的SD卡插入存储设计。
录音总长达63秒,可使用4个频道的接点式控制,也可使用15个频道的二进制控制。

规格

尺寸 - 80mm x 80mm x 94.7mm
额定电压 - 12/24V DC
- 100/220V AC
主体颜色 - 黑色
- 米白色
音量 - 1米处最大87dB
存储内容 - 大约录音时间:63秒(比特率=64k/s)
输出频道 - 通过信号输入到1或4端子,选择4个可用频道中的1个
- 在二进制模式下,通过在4个端子中的信号输入选择15个可用频道中的1个
认证 - CE标志
- RoHS
- MPEG Layer-3音频编码技术,授权自Fraunhofer IIS和Thompson Licensing
保护等级 - IP54
功能 - 音量减少模式,可减少10dB音量

(*)本网站上数据的下载服务被认为已同意以下“”。

(*)本网站上数据的下载服务被认为已同意以下“”。

BDV  

BDV  

更换零件

分类 No. 名称 零件编号 数量 规格 更换的大致时间
插槽防水盖
C25110015-F1 1

-

-

端子盖
C15140003-F1 2

-

-

安装支架(2 个)
V82100001-F1 2

-

-
